INTELLO

Hydrosafe® high-performance vapour check, suitable for all fibrous insulation mats and boards

Item number: 10090 | GTIN: 4026639011190

INTELLO

Advantages

  • Promotes superior drying capacity with hydrosafe® technology
  • Intelligent airtightness system (IAS) for warm, dry, healthy buildings
  • Maximises the performance of thermal insulation
  • Highly diffusion-resistant in winter
  • Superior back-diffusion capacity in summer

Areas of application

INTELLO® is a market leading intelligent air barrier for all construction types, providing superior energy efficiency and moisture control. INTELLO® maximises the performance of thermal insulation while restricting internal moisture from entering the building envelope. INTELLO® utilises hydrosafe® technology, providing optimal protection against structural damage and mould, even in the event of unexpected moisture intrusion.

General conditions

IMPORTANT INFORMATION

  • This product should not be exposed to UV or water during the construction or operation of the building.
  • Class 2 to Class 3 humidity-variable air barrier.
  • Lowest VOC rating in hazardous substance test (ISO 16000).
  • Protected winter building sites thanks to hydrosafe® behaviour.

PRODUCT DESCRIPTION

INTELLO® is an air barrier with smart vapour control, forming part of an intelligent airtightness system (IAS) when joints are sealed with TESCON® VANA, and junctions are sealed with ORCON® Classic. The INTELLO® humidity-variable response is achieved by the polyethylene (PE) copolymer laminated on spun-bonded polypropylene (PP).

WEATHER EXPOSURE

This product should not be exposed to UV or water during the construction or operation of the building.

APPLICATION NOTES

INTELLO® should be laid with the printed side facing the installer, without folds, creases or tears to ensure airtight seals and optimal performance.

Materials
Fleece
Polypropylene
Functional film
Polyethylene copolymer
Properties
Colour
White-translucent
Surface weight
85 ±15 g/m²
Thickness
0.25 ±0.1 mm
sd value mean/humidity-variable
0.25 - >25 m
Vapour resistance (MVTR) humidity variable
1.25 - >125 MN·s/g
Flammability index
< 5
Absorbency
> 100 g/m²
Air resistance
≥ 0.1 MN·s/m³
Type classification
W4
Edge tear resistance MD/LD
158 N / 110 N
Tensile strength MD/LD
3.2 kN/m / 2.0 kN/m
Heat shrinkage @ 70°C MD/LD
0.0% / 0.0%
Moisture shrinkage
0.2%
Temperature resistance
Permanent -40 °C to +80 °C
